Termo hibridinė IP kamera, termo raiška160x120, objektyvas 1mm + 2MP STARLIGHT4mm., IVS, IP67
Features:
• 160x120 VOx uncooled thermal sensor technology
• Athermalized Lens (thermal camera), Focus-free
• 1/2.8” 2Megapixel progressive scan Sony CMOS
• Support ROI, Motion Detection, Color Palettes
• Support Fire detection & alarm
• Built-in 2/1 alarm in/out
• Micro SD memory, IP67
Technical Specifications:
Thermal Camera
• Image Sensor Uncooled VOx Microbolometer
• Effective Pixels 160(H)x120(V)
• Pixel Size 12um
• Thermal Sensitivity (NETD) <50mK@f/1.1
• Spectral Range 7~14um
• Image Setting Brightness/Sharpness/ROI/AGC/FFC/3D DNR
• Color Palettes 14(Whitehot/Blackhot/Ironrow/Icefire/Fusion/Rainbow/Globow/Iconbow1/Iconbow2 .etc)
Thermal Lens
• Lens Type Fixed
• Focus Control Athermalized, Focus-free
• Focal Length 1mm
• Angle of View H: 56° V: 44°
Visible Camera
• Image Sensor 1/2.8" 2M CMOS
• Effective Pixels 1944(H)x1092(V)
• Electronic Shutter Speed 1/1 ~ 1/30,000s
• Min. Illumination Color: 0.005Lux@F1.8; B/W: 0.0005Lux@F1.8; 0Lux(IR on)
• IR Distance 35m
• IR On/Off Control Auto/Manual
• IR LEDs 1
Visible Lens
• Focal Length 4mm
• Max Aperture F1.8
• Angle of View H: 74.8° V: 44.7°
Video
• Compression H.264/MJPEG
Frame Rate
• Main Stream:Thermal: 1280*960 (default)/720P@1~25/30fps Visible: 1080P (default)/720P@1~25/30fps Sub Stream:Thermal: 640*480 (default)/ 320*240@1~25/30fps Visible: CIF(default)/D1@1~25/30fps
• Bit Rate Control CBR/VBR
• Bit Rate H.264: 640 ~ 8192Kbps
• Day/Night Auto(ICR)/Color/B/W
• BLC Mode BLC/HLC/WDR
• White Balance Auto, Manual
• Noise Reduction Ultral DNR
• Motion Detetion Off/On (4 zone, Rectangle)
• Region of Interest Off/On (4 zone)
• Electronic Image Stabilization (EIS) NA
• Defog Off/On
• Flip 180°
• Mirror Off/On
• Privacy Masking Off/On (4 area, Rectangle)
Audio
• Compression G.711a/G.711Mu/AAC
Intelligence
• IVS Tripwire, Intrusion, Object Abandon/Missing
• Advanced Intelligent Functions Fire detection & alarm, Image Fusion
Network
• Ethernet RJ-45 (10/100Base-T)
• Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP,ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP,DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour,802.1x
• Interoperability ONVIF Profile S & G, PSIA, CGI
• Streaming Method Unicast/Multicast
• Max. User Access 10 Users/20 Users
Edge Storage
• micro SD (128GB)
• Memory status display (Normal/Error/Active/Formatting/Lock),
• NAS (Network Attached Storage), Local PC forinstant recording
• Web Viewer • Management Software Smart PSS, DSS
• Smart Phone Android, IOS
Certifications
• Certification CE (EN 60950:2000) FCC (FCC Part 15 SubpartB )
Interface
• Video Interface 1.0Vp-p/75O, PAL/NTSC (HDCVI Optional)
• Audio Interface In/Out 1/1
• RS485 Support
• Alarm 2/1 In/Out
Electrical
• Power Supply DC 12V/PoE
• Power Consumption 12W (IR on), 9W(IR off)
Environmental
• Operating Condition -30°C ~ +55°C (-22°F ~ +131°F)/Less than 95% RH
• Start up should be done at above -30°C (-22°F)
• Strorage Conditions -40°C ~ +70°C (-40°F ~ +158°F)/Less than 95% RH
• Ingress Protection IP67
Construction
• Casing Metal
• Dimensions 238.6mm × 90.4mm× 90.4mm (9.39" x 3.56" x 3.56") (With bracket)
• Weight < 1Kg
