PoE šakotuvas 9-portų 100Mbps
Features:
• 8-Port 10/100Mbps Fast Ethernet Switch
• 8-Port supports 48V DC power to PoE Powered Device
• 1-Port 10/100/1000Mbps Gigabit Ethernet Switch
• Complies with IEEE 802.3af Power over Ethernet End-Span PSE
• Up to 8 IEEE 802.3af devices powered
• Supports PoE Power up to 15.4 watts for each PoE port
• 120-watt PoE budget
• Auto detects powered device (PD)
• Circuit protection prevents power interference between ports
• Remote power feeding up to 100m
• Hardware based 10/100Mbps auto-negotiation and auto MDI/MDI-X (Port 1 to Port 8)
• Hardware based 10/100/1000Mbps auto-negotiation and Auto MDI/MDI-X (Port 9)
• Flow control for full duplex operation and back pressure for half duplex operation
• Integrates address look-up engine, supporting 4K absolute MAC addresses
• Automatic address learning and address aging
• 12-inch desktop size, 1U height
• LED indicators for system power, per port PoE ready and PoE activity, speed, Link / Act
• 1 silent FAN to provide stable and efficient power performance
Technical Specifications:
• Switch Architecture: Store and Forward switch architecture
• MAC Address Table: 4K MAC address table with Auto learning function
• Switch Fabric: 3.6Gbps
• Switch Throughput: .67Mpps@64Bytes
• Flow Control: Back pressure for Half-Duplex. IEEE 802.3x pause frame for full-duplex
• Standard Compliance: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af
• PoE Standard IEEE 802.3af Power over Ethernet / PSE
• PoE Power Supply Type: End-Span
• Per Port 48V DC, 350mA. max. 15.4 watts
• Power Pin Assignment: 1/2(+), 3/6(-)
• PoE Power Budget: 120 watts (at room temperature)
• Max. number of Class 1 PD: 8
• Max. number of Class 2 PD: 8
• Max. number of Class 3 PD: 8
• Power Requirements: AC 100~240V, 50/60Hz, 2A max.
• Power Consumption: 130 watts / 443BTU
• Dimensions: (W x D x H) 280 x 180 x 43 mm, 1U height
• Weight: 1.7kg
