Atstuminių kortelių pirštų skaitytuvas + kontroleris + klaviatūra, RJ45,Wiegand, RS-485
Features:
• Touch keyboard and LCD display
• Support 30,000 valid cards & 150,000 records
• Support multiple cards(default IC card) (“-D” means ID EM card)
• Support card, password, fingerprint and combination
• TCP/IP to PC, support WAN communication
• Support P2P add device
• Wiegand or RS-485 interface to reader
• Door time out alarm, intrusion alarm, duress alarm and tamper alarm
• Anti-passback, multi-card open
• Software attendance
• Support 128 efficient time and holiday schedules
Technical Specifications:
System
• Main Processor 32 Bit
• Flash Memory 32M
• Input/Output Ports
• Input Door sensor x 1, Exit button x 1, Alarm input x 1
• Output Relay x 3 (Door lock, Bell, Alarm x 1)
Card Read
• Read Format 13.56MHz(Mifare)
• Read Range 3-8cm (max.)
• Response Time <0.1s
• Fingerprint Read
• Response Time ?0.5s
• Recognition Time ?1.5s
• FAR ?0.00004%
• FRR ?0.15%
Capacity
• Card holders 30,000
• Events 150,000
• Fingerprint 3000
Function
• Network P2P, DHCP
• Access control Anti-passback, Multi-interlock, Multi-card unlock
• User Management General, VIP, Guest, Patrol, Black list, Duress
• Alarm Function Door time out alarm, Intrusion alarm, Duress alarm, Tamper alarm
• Schedule Setting Support 128 groups of schedule, 128 groups of period and 128 groups of holiday period
Interface
• To PC RJ45(10/100M)
• To Reader Wiegand34/26, RS485
Genreal
• RTC Yes
• Voice Prompt Yes
• Beep Tone Buzzer
• Ingress protection IP65
• Power Supply 9-15DC/200mA
• Working Environment -5°C-+55°C
• Working Humidity ?95%
• Dimension(W×D×H) 210mm*83mm *33mm
• Weight 0.44Kg
