2 durų kontroleris ASC1202B-D
Features:
• Support 100,000 valid cards & 150,000 records
• Support multiple cards
• Support card, password, fingerprint and combination
• TCP/IP interface to PC
• Wiegand or RS-485 interface to readers(2 door)
• Door time out alarm, intrusion alarm, duress alarm and tamper alarm
• Anti-pass back, multi-door interlock, multi-card open
• Support 128 efficient time and holiday schedules
• Watch dog function ensure device free from halting
• Surface mounted installation
Technical Specifications:
System
• Main Processor 32 Bit
• Memory 16M
• Input/Output Ports
• Input Inputs x 8 ( door sensor x 2, exit button x 2, alarm x 4)
• Output Relay x 4(door lock x 2, alarm x 4 )
• Reader Reader x 4
Capacity
• Card holders/Events 100,000/150,000
Function
• Access control Anti-pass back, Multi-interlock, Multi-card unlock
• User Management General, VIP, Guest, Patrol, Black list, Duress
• Alarm Function Door time out alarm, Intrusion alarm, Duress alarm, Tamper alarm
• Period Support 128 groups of schedule, 128 groups of period and 128 groups of holiday period
Interface
• To PC RJ45(10/100M)
• To Reader Wiegand26/34,RS485
Genreal
• RTC Yes
• Power Supply 9-15DC/500mA
• Working Environment -30°C~+60°C
• Working Humidity =95%
• Dimension(W×D×H) 210*51*116mm
• Weight 0.56Kg
