PoE ir LAN praplėtėjas PFT1300
Features:
• Support passive PoE cascade power supply and Ethernet data exchange
• Support IEEE 802.3af/at standard power supply IP Camera
• Cooperate with High PoE Midspan (PFT1200), able to cascade level 2 PoE Extender, connect to 3 IPC (power consumption <=8W), max transmission distance 300m
• 1*RJ45 10/100M PoE power supply input; 1*RJ45 10/100M supply power for IP Cam; 1*RJ45 10/100M supply power for the next extender
• Installation mode: junction box internal mounting, DIN rail mounting
Technical Specifications:
Ethernet Port
• 1*10/100 Base-T PoE power receiving port
• 1*10/100 Base-T PoE power supply port, supply power for the next extender
• 1*10/100 Base-T PoE power supply port, supply power for IPC
Transmission Distance
• Cooperate with DH-PFT1200, able to cascade level two extender, connect to 3 IPC (level one extender connects to 1 IPC, the OUT port of level two extender and CAMERA port connect to 1
IPC respectively, IPC power consumption <=8W), transmission distance is 300m
• Power Consumption <=3W
• Application Humidity 10%~90%
• Working Temperature -30°C~65°C
• Weight 57g
• Dimension(W×D×H) 79mm×52mm×23mm
